Diagnostics for VAG

Autologic covers all VW and Audi vehicles from 1992 — 2011 and all Seat and Skoda vehicles from 1996 — 2011

Full technical specifications are available from www.autologic.com

Guided Functions

Dash Panel & Engine Control Unit Replacement

Using this Autologic feature, the coding options are determined from the old control unit before the new unit is then coded with the correct options. Autologic users do not need to manually set all of the coding options.

Brake Pad Replacement

Vehicles that are fitted with Electric Parking Brake systems require a diagnostic rotten to replace basic service items such as brake pads. Simple to use guided functions on the Autologic step the user through the service process.

Self-Levelling Suspension Calibration

Calibration is necessary after any routine service work of the suspension systems. Autologic is capable of calibrating the suspension systems.

Service Light Reset

There are a growing number of vehicles where servicing is no longer a simple procedure. Al variants are now covered by Autologic VAG.

Dynamic Commencement of Injection

A guided function of Autologic aids the user in adjusting the pump timing of diesel engines. Clear instructions are provided to time the pumps, taking into account the engine's current operating conditions.

Special Functions — TV Enabling

TVs by default, are restricted from being viewed whilst the car is in motion. This limitation can be removed on various vehicles using the specific Autologic TV enabling function.

Fault Code Linked Test Procedures

Associated diagnosis and repair instructions are included for a variety of fault codes. Autologic provides the user with highlighted tests to work through, helping reduce the time pen rectifying a fault.

Descriptive Coding

Understanding the large number of coding options available is always going to be a difficult task. Via the 'Descriptive Coding' feature on the Autologic, the available options are identified are presented in an 'easy-to-use' fashion, permitting the user to configure the car quickly and easily.

Readiness Code Generation

New vehicles are now subject to tight emission laws and regulations which require the vehicles to monitor and flag any related issues in the way in which a car's engine is running. Once reset, the Readiness Codes must then be reinitialised, requiring the car to put through an extensive list of specific driving conditions. Autologic helps the user to sequentially work through each step, ensuring all conditions are met plus, will highlight any potential problem areas.

Side Headings

Guided Functions — Cluster Replacement

With Autologic there is no more manual setting of coding options when replacing clusters for ECUs

Dynamic Commencement of Injection

Aids pump timing of diesel engines

Descriptive Coding Menu

Autologic's ease of use helps users to quickly configure details

New Key Coding

Automatically adapts keys without the need for PIN Codes
